High efficiency: The bucket wheel machine has a strong loading capacity, which can load a large amount of materials at one time and transport them to the destination. Its loading and unloading speed is fast, can complete a large number of handling tasks in a short time, and significantly improve production efficiency. Wide range of applications: bucket wheel machine is not only suitable for large coal, ports and other logistics centers, but also suitable for construction sites, metallurgy, chemical industry and other industries handling and drying work. The adaptability is very wide.
Strong ability of continuous operation: bucket wheel machine adopts continuous operation mode without shutdown, which has greater advantages compared with traditional loading and unloading machinery. High efficiency and reliability: bucket wheel machine has efficient operation capacity and transportation system, which can quickly complete a large number of material handling and stacking work.
有货 SKU:Technical specifications 分类: Stacker Reclaimer 标签: Crawler Mucking Loader, Loader, Mucking Loader, Stacker Reclaimer 品牌: Shante
Product Advantages:
High efficiency: The bucket wheel machine has a strong loading capacity, which can load a large amount of materials at one time and transport them to the destination. Its loading and unloading speed is fast, can complete a large number of handling tasks in a short time, and significantly improve production efficiency. Wide range of applications: bucket wheel machine is not only suitable for large coal, ports and other logistics centers, but also suitable for construction sites, metallurgy, chemical industry and other industries handling and drying work. The adaptability is very wide.
Strong ability of continuous operation: bucket wheel machine adopts continuous operation mode without shutdown, which has greater advantages compared with traditional loading and unloading machinery. High efficiency and reliability: bucket wheel machine has efficient operation capacity and transportation system, which can quickly complete a large number of material handling and stacking work.
Product Introduction:
Bucket Wheel Stacker Reclaimer For Water Conservancy
Superior Productivity: The bucket wheel stacker reclaimer delivers industry-leading loading capacity, enabling seamless bulk material handling and continuous transportation within a single operational sequence. Its hyper-efficient loading/unloading mechanisms drastically shorten task durations, catalyzing revolutionary improvements in industrial throughput.
Universal Adaptability: Precision-engineered for versatility, this machine operates flawlessly across heterogeneous industrial ecosystems—including coal terminals, port logistics clusters, construction zones, steel manufacturing plants, chemical processing facilities, and precision material stacking operations. Its omnidirectional design resolves complex operational challenges, ensuring interoperability in cross-industry applications.
Zero-Downtime Performance: Constructed with military-grade durability, the bucket wheel stacker reclaimer maintains uninterrupted 24/7 operation with 100% uptime, outperforming legacy loading/unloading systems in velocity, structural integrity, and process stability. Precision-Driven Excellence: Propelled by a high-torque electro-mechanical drive and nanoscale-calibrated conveyor systems, the machine executes rapid material transfer with micron-level stacking precision. Integrated AI-optimized predictive analytics and live diagnostics refine operational safety, enable condition-based maintenance, and eradicate system faults, guaranteeing unimpeded production continuity.
Frictionless Maintenance: A modular engineering philosophy permits instantaneous component replacement and maintenance simplification, eliminating operational interruptions and total cost of ownership. Pre-engineered subassemblies ensure direct access to mission-critical components, sustaining peak operational readiness and lifecycle efficiency.
Intuitive Operational Mastery: Featuring human-centric control ergonomics and an AI-assisted interface, operators achieve competency within minimal training cycles. Command of core operational protocols, aligned with stringent safety governance, ensures relentless high-efficiency output—democratizing access to advanced machinery without specialized expertise.
Bucket Wheel Stacker Reclaimer For Water Conservancy | |||
Project | unit | Technical specifications | |
Overall dimensions - L×W×H | mm | 21090×4000×5888 | |
track size | mm | 5700×600 | |
Width of track shoe | mm | 600 | |
Track drive hydraulic motor | / | Hydraulic motor+reducer | |
Teack drive hydraulic pump | / | Danvers | |
Hydraulic pump drive motor | kw | 45 | |
Bucket wheel arm length | mm | 8280 | |
Length of discharge arm | mm | 8000+3000 | |
Rated output | m³/h | 900 | |
Bucket wheel diameter | mm | 3600 | |
Bucket wheel speed | r/min | 0-8 | |
Volume of each bucket wheel | m³ | 0.3 | |
Number of buckets | piece | 8 | |
Pitch angle of bucket wheel | ° | 25~-5 | |
Material density | t/m³ | 0.8~1.8 | |
Turning radius of bucket wheel | mm | 10036 | |
Width of reclaiming conveyer belt | mm | 1200 | |
Bucket wheel rotation angle | ° | ±180 | |
Width of discharge conveyer belt | mm | 1000 | |
Length of discharge conveyer belt | mm | 29524 | |
Rotation angle of discharge conveyer belt | ° | ±65 | |
Pitch angle of discharge conveyer belt | ° | 0-16 | |
Max stack height of discharge conveyer belt | mm | 6500 | |
Driving form of telescopic mechanism | / | Hydraulic cylinder | |
Overload protection mode of bucket wheel | / | Automatic | |
Matching motor power | Track travel drive | kW | 45 |
Bucket wheel swing drive | kW | 75 | |
Bucket wheel conveyer belt drive | kW | 15*2 | |
Outfeed conveyer belt drive | kW | 15*2 | |
Engine power | Track travel drive | kW | 105 |
尺寸 | 21090 × 4000 × 5888 毫米 |
---|---|
Industries Served | Chemical, Coal Mine, Construction, Hydropower, Metal Mine, Metallurgical, Military Engineering, Non-Metal Mine |
Applications | Cable Duct, Caverns, Construction Tunnel, Culverts, Drainage Tunnels, Hydraulic Channel Tunnel, Inclined Shaft, Military Passageways, Mine, Mining Site, Mining Tunnels, Traffic Tunnels, Tunnels, Utility Tunnels |
Scenarios | Block Load, Breaking, Convey, Dig, Excavate, Floor Clean, Muck&Load |
Track Size(mm) | |
Width of track shoe(mm) | |
Track drive hydraulic motor | |
Teack drive hydraulic pump | |
Hydraulic pump drive motor(kw) | |
Bucket Wheel Arm Length(mm) | |
Length of Discharge Arm(mm) | |
Rated Output(m³/h) | |
Bucket Wheel Diameter(mm) | |
Bucket wheel speed(r/min) | |
Volume of each bucket wheel(m³) | |
Number of Buckets (piece) | |
Pitch angle of bucket wheel( °) | |
Material Density(t/m³) | |
Turning radius of bucket wheel(mm) | |
Width of reclaiming conveyer belt(mm) | |
Bucket wheel rotation angle( °) | |
Width of discharge conveyer belt(mm) | |
Length of discharge conveyer belt(mm) | |
Rotation angle of discharge conveyer belt( °) | |
Pitch angle of discharge conveyer belt(°) | |
Max stack height of discharge conveyer belt(mm) | |
Driving form of telescopic mechanism | |
Overload protection mode of bucket wheel | |
Matching motor power Track travel drive(kw) | |
Matching motor power Bucket wheel swing drive(kw) | |
Matching motor power Bucket wheel conveyer belt drive(kw) | |
Matching motor power Outfeed conveyer belt drive(kw) | |
Engine Power Track travel drive(KW) | |
Customizable |
