Mingnao Heavy Industry
| Project | Unit | MWD8/0.4L |
| working body | / | Three section arm |
| Motor power | kw | 55kw |
| bucket capacity | m3 | 0.4m3±0.03 |
| digging radius | mm | ≥4460mm |
| Excavation depth | mm | ≥1630mm |
| Excavation height | mm | ≥5400mm |
| Dumping height | mm | ≥2270mm |
| Auxiliary arm angle | 。 | ±90。 |
| Body rotation angle | 。 | 360。 |
| Walking form | / | Crawler walking |
| ground pressure | Mpa | ≤0.1Mpa |
Product Features:
1. It has the characteristics of compact structure, energy saving, low noise, multiple functions, and high efficiency. It is suitable for excavation, contour repair, undercover, belt bottom side excavation, crushing, cleaning floating coal, slag removal, leveling tunnels, and loading operations in coal mine section tunnels. It has good disassembly and is easy to move and transport underground.
2. The auxiliary arm of the working mechanism can rotate ± 90 °, and the upper platform can rotate 360 °.
3. Equipped with a vehicle mounted methane power-off device, automatic power-off is achieved when the underground gas concentration exceeds the standard.
4. Equipped with a bulldozer shovel to level the roadway floor and stabilize the machine body.
5. The hydraulic system adopts well-known brand load sensitive control technology to reduce energy consumption.
