Mingnao Heavy Industry
| Project | Unit | BH27 (Basic Type) |
| Pilot operation/manual operation | kg | 8500kg |
| Transportation dimensions (length, width, height) | m | 6.1x1.6x1.95 |
| Maximum positioning cutting height | mm | 3100mm |
| Maximum positioning cutting width | mm | 3500mm |
| Total installed power | kw | 55kw |
| power supply voltage | v | AC660/1140 |
| Cutting power | kw | 35kw |
| Cutting head speed | rpm | 0-100rpm |
| External spray water pressure | MPa | 1.5MPa |
| Economical cutting hardness | MPa | 50/40MPa |
| Undercover depth | mm | 370mm |
| ground pressure | Mpa | 0.06 |
| gradeability | ° | ≤25 |
| walking speed | min | 22min |
| Working pressure of the main hydraulic system | MPa | 24.5/22/16 |
| Hydraulic system form | Load sensitive/constant power system | |
| Scraper chain speed | m/s | 0.43 |
| conveying capacity | m3/h | 50 |
| Form of loading mechanism | Three toothed star wheel |
